Black Steel Case Micro Pressure Gauge MP-EPG

Black Steel Case Micro Pressure Gauge
Model: MP-EPG

Introduction
MP-EPG micro pressure gauge with affordable price is suitable for micro pressure measurement in media compatible with liquid and gas.

Features
■ OEM service
■ General type micro pressure gauge with affordable price
■ Specially design for micro pressure measurement

Main specifications
▼Size
2”, 2.5”, 3”, 4”
▼Installation type
Bottom mount (A)／Bottom mount with flange (B)／
Back mount (ADC)／Back mount (eccentric thread) (ADE)／Back mount with flange(BDC)
▼Window
Glass (standard)
Option: PC／Acrylic／Safety glass
▼Pressure connection
Material: copper alloy
Size: 1/4”, 3/8”, 1/2”
Spec.: BSPT, NPT, PF
Other thread specs please specify before order
▼Pressure range
Min. 300 mmAq
Max. 6000 mmAq
▼Applicable media
Liquid and gas that compatible with copper alloy
▼Ambient temperature
-40°C to +60°C
▼Fluid temperature
-20 C to +60°C
▼Temperature drift
Every 12°C
Max. error ±0.3% F.S
▼Protection level
IP43

Other specifications
▼Ring
Steel with black enamel
▼Ring mount
Snap-in／Screw fixed
▼Case
Steel with black enamel
▼Pointer
Aluminum with black enamel
Knife edge pointer (For Size > 3” only)
▼Dial face
Blue & black scale
Adjustable screw on dial face
Other pressure unit, scale & color available upon request
▼Measuring elements
Capsule
Material: copper alloy
▼Movement
Copper alloy
▼Accuracy
±4.0%F.S. (Standard)
±3.0%F.S. (Option)
▼Operating pressure
Stabilization 3/4* full scale
Fluctuation 2/3* full scale
