Digital Pressure Gauge
Bluetooth Rotating Digital Pressure Gauge DPG-X182R
Bluetooth Rotating Digital Pressure Gauge DPG-X182R
The DPG-X182R is a digital pressure gauge with a built-in high-precision pressure sensor, known for its high accuracy and long-term stability. It features a large screen, zeroing function, backlight, low voltage alarm, and a dial that can rotate 330° for easy reading from any angle. It supports Bluetooth connectivity and app configuration for parameter settings. Suitable for portable pressure measurement, equipment matching, and calibration in the field of pressure measurement.
DETAIL
Model: DPG-X182R
Introduction
The DPG-X182R is a digital pressure gauge with a built-in high-precision pressure sensor, known for its high accuracy and long-term stability. It features a large screen, zeroing function, backlight, low voltage alarm, and a dial that can rotate 330° for easy reading from any angle. It supports Bluetooth connectivity and app configuration for parameter settings. Suitable for portable pressure measurement, equipment matching, and calibration in the field of pressure measurement.
Features
■ OEM service
■ Large LCD screen with multiple unit switching
■ Dial can rotate 330°
■ Supports Bluetooth connectivity, app configuration, and more
■ Low power design with a battery life of up to 12 months
Main Specifications
▼Dial Diameter
75mm*85mm
▼Connection
Material: Stainless steel 304
M20*1.5, G1/4”, G1/2”, 1/2”NPT, 1/4”NPT
Other specifications can be customized
▼Pressure Range
-0.1~0~0.1…1…60 MPa
▼Addlicable Fluid
Compatible with non-corrosive gas or liquid
▼Operation Temperature
-20℃~65℃
▼Protect level
IP54
Other Specifications
▼Case material
TPE+ABS
▼Screen Display
45mm*33mm
Maximun 5-digit LCD
White backlight
▼Pressure unit
MPa, bar, kgf/cm2, mH2O, psi, kPa, mmHg, mbar, mmH2O, Pa, inWC
<Units provided based on the range>
▼Power supply
3V (AAA battery*2)
▼Battery Life
12 months (Actual usage may vary)
▼Accuracy
±0.5%F.S. / ±0.2%F.S.
▼Long-term Stability
±0.5%F.S. / year
▼Overpressure
200%
▼Electrical Protection
Electromagnetic interference resistance design
