Filter + Regulator + Lubricator Combination Units FRL 3000/4000/5000
Filter + Regulator + Lubricator Combination Units FRL 3000/4000/5000
FRL combined with pneumatic particulate / moisture separation gas line filters, adjustable pressure regulators and lubricator. It has widely applied in pneumatic gas line filtering, regulation, and lubricating with all-in-one single convenient unit.
DETAIL
Model: FRL 3000/4000/5000
Introduction
FRL combined with pneumatic particulate / moisture separation gas line filters, adjustable pressure regulators and lubricator. It has widely applied in pneumatic gas line filtering, regulation, and lubricating with all-in-one single convenient unit.
Features
■ Filter, Regulator and Lubricator combined design
■ With overflow function
■ Differential drain and automatic drain
■ Attached with a mounting bracket
■ Regulators come with a pressure gauge and protective cover
■ Outsourcing parts were selected and tested very strictly to ensure its quality
Main specifications
▼Dimension
FRL 3000: 181 x 156.5 mm
FRL 4000: 238 x 191.5 mm
FRL 5000: 300 x 267 mm
▼Pipe joint bore
FRL 3000: 1/4”, 3/8”
FRL 4000: 3/8”, 1/2”, 3/4”
FRL 5000: 3/4”, 1”
Specification: G, PT, NPT
▼Gauge connection
FRL 3000: 1/8”NPT
FRL 4000: 1/4”NPT
FRL 5000: 1/4”NPT
▼Adjustable Pressure Range
0.05 to 0.85MPa
▼Max Adjustable Pressure
1.0Mpa
▼Operating temperature
5 to 60℃
▼Recommended oil use
ISO VG 32
Other Specifications
▼Body material
Aluminum die casting / Stainless steel
▼Container material
Polycarbonate
▼Rated flow
FRL 3000 – 1700 L/min
FRL 4000 – 3000 L/min
FRL 5000 – 4500 L/min
▼Filtering element roughness
25u
▼Max operating pressure
1.0MPa
▼Ensured pressure resistance
1.5MPa
▼Drain function
Differential drain / Automatic drain
▼Valve
With overflow function
